Ride 1 Up Revv 1 FS

Revv 1 FS – Electric Bike Specifications

Motor & Powertrain

• Motor: 52V Bafang RM G0F4.1000 mid-drive motor

• Controller: 52V 35A boost with 18 MOSFETs for smooth power delivery

• Battery: 52V 20Ah Samsung 50E 21700 cells (56 cells), UL 2271 certified

• Display: 3.5" center mount with watt & RPM bars and turn signal indicators

• Pedal Assist Sensor: Ride1Up R1CBC (Current-Based-Cadence System)

• Throttle: Right-hand twist throttle

Brakes & Suspension

• Brakes: 4-piston LBN hydraulic disc brakes with 203mm rotors and electric cut-off sensor

• Front Fork: Double-crown suspension, 120mm travel, preload & rebound adjustable, hydraulic lockout

• Rear Suspension: DNM AOY-38RC, adjustable rebound, air pressure, and lockout

Ergonomics & Controls

• Handlebar: 720mm width, 25° sweep, 120mm rise

• Stem: Promax, 45mm height, 6° rise

• Grips: Anti-slip rubber

• Saddle: Customized cafe style

Drivetrain & Wheels

• Chainring & Cranks: 42T chainring, 127mm cranks

• Chain: KMC Pro

• Tires: CST Scout eMoped all-surface, 20” x 4.0”

• Fenders: Hardened alloy

Lighting & Accessories

• Front Light: Moto-style round headlight, 120 LUX, with high & low beam

• Rear Light: Starunion brake light with rear turn signals (included on FS frame)

• Pedals: Alloy black
